Mission Magnum XP 14X12X22 Blender Pump

General Introduction

Mission Magnum XP pumps are single stage centrifugal mud pump. They are applied to barite & mineral oil based drilling mud, bentonite, salt water slurry, chemical industry, etc. Thick, strong, concentric casing with replaceable casing wear pad provides extended life over conventional volute designs. Wide semi-open impeller creates lower axial thrust for improved bearing life, and semi-open design reduces the concentration of solids behind the impeller, extending the life of the mechanical seal or packing and stuffing box. There are two mechanical seal alternative, single or double mechanical seal. This stuffing box can be configured for flush lines.

Mission Magnum XP 8x6x18, 12x10x23 and 14x12x22 Blender Pumps are ideally suited for pumping high volumes of heavy slurries that are abrasive, corrosive. An excellent choice for high volume mobile and stationary applications where a small footprint is critical. The low stuffing box pressure can increase seal life approximately 50%. The extra-heavy shaft is designed for minimum deflection. The heavy duty bearings are permanently lubricated to minimize maintenance.

Mission Magnum XP Pump Features:

● Ideally for pumping high volumes of heavy slurries

● Compact structure, with small footprint

● Flow rates 3000-7500 GPM

● Head pressure 75~410 feet

● Material in hard iron, high chrome iron, High chrome alloy or hard iron material options for different applications

● Equivalent to MCM XL 14x12x22 blender pump

● Perfect for slurries of abrasive, corrosive, plain tough to pump

● Designed for continuous operation and minimal maintenance

● Widely used on Frac trucks for blending

● 100% compatible with NOV Mission Magnum XP, MCM XL series and current market offerings.

. The pumps can be unitized with Ex-proof electric motors, diesel engines in-line or over-belt driven configuration.

* Mission Magnum XP Blender Pump Information:

● S- 650120009/ 14 x 12 x 22 Hard Iron Centrifugal Booster Pumps, Mechanical Seal

● S- 650120010/ 14 x 12 x 22 High Chrome Centrifugal Blender Pumps, Mechanical Seal

● S- 666001001/ 12 x 10 x 23 Hard Iron Centrifugal Pumps, Mechanical Seal

● S- 666001007/ 12 x 10 x 23 High Chrome Centrifugal Pumps, Mechanical Seal

● S- 66001005/ 8 x 6 x 18 Hard Iron Centrifugal Pumps, Mechanical Seal

● S- 666001006/ 8 x 6 x 18 High Chrome Centrifugal Pumps, Mechanical Seal

Mission Magnum XP Pump Applications

● Blending on frac trucks

● Transferring Sand slurry/Sewage/Waste Slurry/Slag/Boat Mud

● Lead and Zinc ore and tailings /Dredge tailings

● Copper, bauxite, and quarry slurries

● Mineral Mining

● Nickel shot/Spent liquor/Flay ash/Bottom ash

● Paper Pulp Processing

Sunbo Machinery is a professional manufacturer of slurry pumps, mission pumps and ANSI pumps in China. Our pump products are widely used in mining, mineral processing, tailing handling, dredging, construction, metallurgy, power plants, sewage water treatment, oil and gas drilling and fracturing, food, as well as chemical and petroleum industry.

Mission Magnum XP Pump Parts List
