Conforming to ASME (ANSI) B73.1 Durco Mark Ⅲ process pump, Durco Mark 3 pump incorporate many proven reliability-and performance-enhancing features. They are available in a wide range of configurations, including mechanically sealed, dynamically sealed, sealless magnetically driven, low-flow, self-priming and recessed impeller. It provides flexibility and breadth of pumping solutions in countless applications.
Features:
★ Lower total cost of ownership from reverse vane impeller, which eases maintenance and provides renewable, high-efficiency performance over the pumps' life
★ Increased reliability and mechanical seal life due to the ideal seal environment seal chamber
★ Ease of maintenance resulting from optimal, predictable seal chamber pressures that are re-established after every impeller setting
★ Extended mechanical seal and bearing life through robust shaft and bearing designs that also minimize shaft deflection
★ Fast and accurate impeller setting with the industry's most innovative external impeller adjustment mechanism
★ In-shop reverse vane impeller adjustment with the only pump that takes full advantage of the back pull-out design
Specification:
ASME B73.1 Chemical Process Pump Specification
● Flows to 4540 m³/h (20000 gpm)
● Heads to 215 m (700 ft)
● Pressures to 27 bar (400 psi)
● Temperatures from -75 (-100F) to 370 (700F)
ANSI Pump Size Range:
Sizes from 25 mm (1 in) to 200 mm (8 in)
ANSI Pump Application:
★ Power
◇ Conventional Steam
◇ Combined Cycle
◇ Concentrated Solar Power (CSP)
◇ Biomass & MSW
◇ Geothermal
★ Chemicals
◇ Basic (Organic & Inorganic)
◇ Specialty (Fine & Consumer)
◇ Biofuels
◇ Pharmaceutical
◇ Petrochemicals
★ Water
◇ Water Management
◇ Desalination
★ Oil & Gas
◇ Upstream Exploration & Production
◇ Midstream Transportation
◇ Downstream Processing
★ General Industries
◇ Pulp & Paper
◇ Mining
◇ Food & Beverage
◇ Corn Wet Milling & Ethanol
◇ Other Industries
Available ANSI Pump-Durco Mark 3 Pump Model List
| G series avaliable list (Gould's 3196 equivalent) | D series avaliable list (Durco Mark III equivalent) |
| 1x1.5-6 | 1.5x1-62 |
| 1x1.5-8 | 1.5x1-82 |
| 1x1.5LF-8 | 1.5x1LF-82 |
| 1.5x3-6 | 3x1.5-62 |
| 1.5x3-8 | 3x1.5-82 |
| 2x3-6 | 3x2-62 |
| 2x3-8 | 3x2-82 |
| 3x4-8 | 4x3-82 |
| 3x4-8G | 2x1-10A |
| 1x2-10 | 3x1.5-10A |
| 1x2LF-10 | 3x2-10 |
| 1.5x3-10 | 3x2-10A |
| 2x3-10 | 4x3-10 |
| 3x4-10 | 4x3-10H |
| 3x4-10H | 6x4-10 |
| 4x6-10 | 6x4-10H |
| 4x6-10H | 3x1.5-13 |
| 1.5x3-13 | 3x2-13 |
| 1.5x3LF-13 | 4x3-13 |
| 2x3-13 | 4x3-13HH |
| 3x4-13 | 6x4-13A |
| 4x6-13 | 8x6-14A |
| 6x8-13 | 10x8-14 |
| 8x10-13 | 10x8-16 |
| 8x10-15 | 6x4-16 |
| 8x10-15G | 8x6-16 |
| 6x8-15 | 8x6-16 |
